Belt cleaners and scrapers
Primary, secondary and return-side cleaners matched to the belt, the pulley and the material
A belt cleaner system scrapes carry-back off the belt at and just past the discharge, so material does not travel back under the conveyor and build up on the return idlers, the tail pulley, the take-up and the structure. Most conveyors run a primary cleaner on the head pulley and a secondary cleaner immediately after it; heavy carry-back or sticky material adds a tertiary or return-side cleaner. The right combination depends on the belt, the pulley and what is being conveyed.
Overview
What belt cleaners and scrapers covers
A belt cleaner system scrapes carry-back off the belt at and just past the discharge, so material does not travel back under the conveyor and build up on the return idlers, the tail pulley, the take-up and the structure. Most conveyors run a primary cleaner on the head pulley and a secondary cleaner immediately after it; heavy carry-back or sticky material adds a tertiary or return-side cleaner. The right combination depends on the belt, the pulley and what is being conveyed.
Options
Blades and tensioners
| Item | Where it fits |
|---|---|
| Polyurethane blade | General-purpose primary cleaning. Hardness and compound vary by duty; a wear item, replaced on a schedule. |
| Tungsten-carbide-tipped blade | Secondary and hard-duty cleaning, and abrasive material. Longer edge life; matched to the belt cover and splice. |
| Ceramic segments | Very abrasive, high-tonnage or high-wear duties where tipped blades wear too fast. |
| Spring / linear tensioner | Simple constant-force tensioning for lighter primary and secondary cleaners; low maintenance. |
| Rotary / torsion tensioner | Adjustable blade-to-belt pressure, re-set as the blade wears; common on primary cleaners. |
| Air / pneumatic tensioner | Consistent pressure with remote or automatic adjustment on larger or critical systems. |
Choosing
Cleaner positions on the conveyor
| Position | Where it sits | What it does |
|---|---|---|
| Primary (pre-cleaner) | Against the head-pulley face, below the material trajectory | Removes the bulk of the carry-back. Full-width blade — polyurethane or tipped — held to the belt by a tensioner. |
| Secondary | Just past the head pulley, off the pulley arc | Takes off the thin film the primary leaves. Usually segmented, individually sprung blades, often tungsten-tipped. |
| Tertiary / return-side | Along the return run or at the tail | Catches the last carry-back and protects the tail pulley, take-up and return idlers on heavy or sticky duties. |
| Specialty | At the head, or a dedicated washbox | Belt washboxes, brush cleaners and food-grade scrapers for wet, sticky or hygiene-sensitive material. |
Selection
How we select it with you
Send us as much of the following as you have. Partial information is fine — our engineer will come back with the questions needed to finalise the spec, or attend site for an engineering assessment where the problem needs diagnosing first.
- 01Belt width, belt speed and direction (single or reversing)
- 02Head-pulley diameter and whether it is lagged
- 03Belt splice type — mechanical fasteners or vulcanised
- 04Material — wet / dry / sticky, abrasiveness, lump size and temperature
- 05The discharge trajectory and the space available at the head chute
- 06If replacing blades: the existing cleaner make and model, or the blade width, profile and pole size, with a photo
Applications
Where we supply
- Mine and quarry conveyors — coal, ore, aggregate and mineral handling
- Bulk terminals, stockyards and transfer towers
- Cement, lime and clinker handling
- Sticky and wet materials — washed product, filter cake, fines
- Reversing belts, where the cleaner must work in one direction only
- Food-grade and washdown duties with the correct blade and materials
What we supply
Range at a glance
- 01Primary (pre-)cleaners mounted on the head-pulley face
- 02Secondary and tertiary cleaners for the residual film and the return run
- 03Polyurethane, tungsten-carbide-tipped and ceramic blade options
- 04Spring, rotary/torsion and pneumatic tensioners
- 05Replacement blades and pole / shaft assemblies cross-referenced from your existing cleaner
- 06Belt washboxes, brush cleaners and food-grade scrapers for specialty duties
- 07On-site fitting, tensioning and blade changes with the engineering team
Buyer questions
Common questions
Related
Request a quote
Send your belt cleaners and scrapers requirement
Not sure which spec you need? Send the machine, material and duty details — our engineer will specify the correct product and quote it.
